Features · Built-in DSP processor system · Wide voltage support, 90-250V · Overtemperature protection overload power control · Output DC protection · Peak limiting pressure limiter
· Energy dynamic analysis technology · Dynamic Distortion Compensation Technology · Power undervoltage protection · Module temperature, voltage, current, and fault status monitoring for each channel
· Temperature power control
Power Amplifier | D62 | D63 | D64 | D34 | D35 |
DC-Impedance | 4.8/4.8 | 2.4/2.4/ 4.8/Parallel | 2.4/2.4/ 2.4/2.4 | 3.2/3.2/ 3.2/3.2 | 3.2/3.2 |
Peak output voltage | 200/200 | 100/100/ 200/Parallel | 100/100/ 100/100 | 100/100/ 100/100 | 100/100 |
Peak output current | 40/40 | 40/40/ 40/Parallel | 40/40/ 40/40 | 30/30/ 30/30 | 30/30 |
Max output power | 4000/4000 | 2000/2000/ 4000/Parallel | 2000/2000/ 2000/2000 | 1500/1500/ 1500/1500 | 1500/1500 |
Total output power | 6000 | 6000 | 6000 | 4000 | 4000 |
Maximum Input voltage | +6dBu | +6dBu | +6dBu | +6dBu | +6dBu |
Modulation frequency | 350kHz | 350kHz | 350kHz | 350kHz | 350kHz |
Total Harmonic Distortion | < 0 .03% | < 0 .03% | < 0 .03% | < 0 .03% | < 0 .03% |
Frequency response | 10Hz - 22 KHz | 10Hz - 22 KHz | 10Hz - 22 KHz | 10Hz - 22 KHz | 10Hz - 22 KHz |
SN ratio | 100dB | 100dB | 100dB | 100dB | 100dB |
Efficiency | >80% | >80% | >80% | >80% | >80% |
Power factor | >0.85 | >0.85 | >0.85 | >0.85 | >0.85 |
Standby consumption | 10w/25w | 10w/25w | 10w/25w | 10w/25w | 10w/25w |
Power supply range(AC/DC) | 90~250V | 90~250V | 90~250V | 90~250V | 90~250V |
Dimensions WHD(mm) | 480x44x200 | 480x44x200 | 480x44x200 | 480x44x200 | 480x44x200 |
Weight Kg | 4 | 4 | 4 | 4 | 4 |
